3.5hp Hermetic Scroll Compressor ZR42K3-TFD-522 For Refrigeration Ac Split Unit Parts

Model Number : ZR42K3-TFD-522

height : 419.3

Capacity(w) : 10300

After-sales Service : Online support

EER : 11.1

Displacement/ m3/ : 9.94

Horse Power : 3.5HP

Type : Compressor

Voltage : 220V/1Ph/50Hz

Input power(kw) : 3.12

Product Name : Air-Conditioning Scroll Compressor

Cooling Capacity (Bt : 35000

Certification : CE 3C

Place of Origin : CHINA

MOQ : 1

Payment Terms : T/T

Supply Ability : 5,000pcs per month

Delivery Time : 1-7 working days after receiving payment

Packaging Details : 16PCS / Pallet

Contact Now

3.5hp Hermetic Scroll Compressor ZR42K3-TFD-522 For Refrigeration AC Split Unit Parts

Product Overview

Factory supplier scroll compressor ZR42K3-TFD-522 scroll compressor refrigeration compressor

Key Specifications

Model	ZR42K3-TFD-522
Production Capacity	1000 Piece/Pieces per Month
Color	Black compressor
Exhaust Capacity	9.94 m³/h
Horse Power (HP)	3.5
Weight	29.9 kg
Guarantee	1 year
Type	Hermetic scroll compressor
Cooling Capacity	10100 W

Application & Operating Parameters

ZR series scroll compressor can be used for air conditioning and refrigeration.

Refrigerant: R22

Volt/Hz: 220/380V 50/60 Hz

Compressor Features

Outstanding reliability
Fewer moving parts
Compliance feature offers unprecedented liquid handling capability
Internal motor protection from high temperature and high current
Very low noise/gas pulsation
Five decibels quieter than piston compressor
Simplified system design
Unique unload start feature requires no start capacitors/relay
High heat pump capacity due to nearly 100% volumetric efficiency
Selection scope ranges from 1HP to 30HP, and is expanding

Technical Data - Three Phase Models

Model	Horsepower (HP)	Refrigerating Capacity (W)	Input Power (W)	Electricity (A)	Displacement	Oil Capacity (L)	Net Weight (KG)	Locked-Rotor Current (A)	Noise Power
ZR26KM	2.2	6250	1970	9.9	34.6	0.77	19.6	53.0	63.0
ZR38KM	2.3	6750	2020	9.2	37.2	0.77	19.4	52.9	63.0
ZR30KM	2.5	7350	2190	10.1	40.5	0.77	19.3	52.9	63.0
ZR32KS	2.7	7900	2410	10.9	44.3	0.74	22.1	66.0	68.0
ZR34KH	2.8	8200	2520	13.6	46.2	1.04	30.4	100.0	66.0
ZR36KH	3.0	8900	2730	13.6	49.5	1.24	30.4	100.0	68.0
ZR39KH	3.3	9850	3000	14.6	54.2	1.24	30.4	114.0	68.0
ZR42K3	3.5	10250	3150	15.2	57.2	1.24	30.4	97.0	68.0
ZR45K3	3.8	11200	3380	16.4	61.1	1.24	32.2	114.0	68.0
ZR47K3	3.9	11550	3460	16.8	63.3	1.24	31.3	114.0	68.0
ZR48K3	4.0	11850	3630	17.6	65.5	1.24	31.3	114.0	68.0
ZR61KC	5.1	14950	4550	21.7	82.6	1.66	42.6	150.0	71.0
ZR68KC	5.7	16700	5130	24.5	93.0	1.83	40.4	150.0	72.0

Technical Data - Single Phase Models

Model	Power (HP)	Exhaust Capacity M³/h	Refrigeration Capacity (W)	Input Power (W)	Weight (Kg)	Height (mm)
ZR16K3-PFJ	1.33	3.97	4010	1320	25.9	370.4
ZR18K3-PFJ	1.50	4.37	4400	1440	25.9	370.4
ZR20K3-PFJ	1.69	4.76	4890	1600	25.9	370.4
ZR22K3-PFJ	1.83	5.34	5330	1730	25.9	382.8
ZR24K3-PFJ	2.00	5.92	5920	1870	26.3	382.8
ZR26K3-PFJ	2.17	6.27	6330	2000	25.9	382.8
ZR28K3-PFJ	2.33	6.83	6910	2150	27.2	382.8
ZR30K3-PFJ	2.50	7.30	7380	2290	28.5	405.5
ZR32K3-PFJ	2.67	7.55	7760	2410	28.1	405.5
ZR34K3-PFJ	2.83	8.02	8200	2520	29.5	405.5
ZR36K3-PFJ	3.00	8.61	8790	2700	29.5	405.5
ZR40K3-PFJ	3.33	9.43	9670	2970	29.9	419.3

3.5hp Hermetic Scroll Compressor ZR42K3-TFD-522 For Refrigeration Ac Split Unit Parts
